FTTH Cable Production: Manufacturing Process Explained
Did you know: in excess of 70% of U.S. broadband rollouts now use fiber networks that require high-precision manufacturing to meet performance goals.
Shanghai Weiye OFC Equipment runs end-to-end compact fiber unit manufacturing, from selecting brand fibers like Fujikura or Corning SMF-28e to comprehensive test documentation that deliver 100% QA.
Our drop cable designs fit overhead, underground, and direct-buried installation, with LSZH, PVC, and polyethylene (PE) jacket options and arrangements from 1–4 cores. We offer OS1/OS2 and multimode OM2–OM4 grades plus ITU-T G.652D and ITU-T G.657 variants, Pantone sheath colors, and logo printing.
Automation and high-precision equipment keep line speed steady and repeatability high. Typical lead times run 4–5 days for orders under 100 km and 7–10 days for < 500 km, with an MOQ of 1 km and warranty covering free replacement for confirmed quality issues.
Keep reading to understand how our materials, tests, and support work together to reduce lifecycle cost and align the product to your network needs.
- Shanghai Weiye OFC Equipment provides complete production and laboratory testing for United States projects.
- Multiple jacket choices and optical grades fit different install environments.
- Automated lines and machines ensure stable quality and reliable optical performance.
- Fast lead times, low minimums, and brand fiber options support reliable procurement planning.
- Comprehensive test reports and warranty support product reliability and compliance documentation needs.
Specialized FTTH Manufacturing by Shanghai Weiye OFC Equipment
When deadlines and performance are critical, Shanghai Weiye OFC Equipment delivers customized drop cables with complete test documentation.
As a dedicated manufacturer, Shanghai Weiye OFC Equipment pairs purpose-built equipment with tight material control. We offer customized service and products for single-family and MDU rollouts. Every order includes full QA coverage and complete test reports.
Our lab conducts high-temperature, salt-fog, and vibration tests to verify durability. Jacket options include LSZH, PVC, and PE. Designs include flat bow-type and self-supporting styles and support brand fibers such as Fujikura and Corning® SMF-28e.
- Controlled production lines and in-process checks for fully auditable shipments.
- Engineering support for specs, trials, and ramp to volume.
- Modern fixturing and calibration reduce variability so every cable meets carrier standards.
FTTH cable production
At Shanghai Weiye OFC Equipment, manufacturing steps are matched to network specs, pairing brand fiber choices with disciplined test flows.
Fiber Selection & Brand Options
We select fiber secondary coating line to minimum bend radius, loss, and install environment. Options include OS1, OS2, OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura® and Corning SMF-28e are available to satisfy sourcing standards.
Strength Member Options
Strength members use dielectric FRP or galvanized steel wire. FRP is preferred where non-conductivity is necessary. Steel wire provides tensile strength for long-span aerial runs and bonding/grounding needs.
Extrusion & Process Control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Tight process control of temperature and capstan ratios keeps line speed stable and dimensional tolerances.
| Member | FRP | Steel wire |
|---|---|---|
| Use case | Non-conductive runs | High-tension aerial runs |
| Key benefit | Light, non-corrosive | Very high tensile strength |
| Installer note | Simple terminations | Requires grounding |
Inline and final testing
Inline geometry/concentricity checks run during manufacturing. Final optical tests verify loss and return loss. Each order ships with a full test report and lab results from high-temperature, salt-spray, and vibration tests to qualify field handling and drop terminations.
Typical lead times are 4–5 days for < 100 km and under 500 km in 7–10 days. Material lot records and FAI approvals support traceability and compliance for U.S. projects.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment offers a focused portfolio of FTTH drop designs that cover tight indoor routes and exposed aerial spans. Each option combines tested materials with field-termination geometry and consistent optical performance.
The bow-type flat drop cable keeps a small footprint for risers and conduit. It reduces bend loss for simple routing in MDU corridors and hallways.
Self-supporting designs for aerial spans
Self-supporting FTTH drop designs use a support messenger to carry tensile loads. Choose dielectric FRP for non-conductive runs or steel wire when bonding and extra tensile strength are required.
Core Layouts and Strength Members
We offer both dielectric and metallic strength member configurations to meet safety/EMI requirements. Center loose tube and flat unitube types balance crush resistance and Fiber draw tower for quick termination.
Indoor/outdoor jackets
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor UV and moisture resilience. Each family is qualified for mechanical and optical quality before shipment.
| Design | Application | Strength member | Jacket |
|---|---|---|---|
| Bow-type flat | Indoor risers and MDUs | Dielectric FRP | Low-smoke zero-halogen |
| Self-supporting | Aerial spans | FRP/Steel | Polyethylene |
| Center loose tube | Higher-count builds | FRP | LSZH/PE |
| Unitube flat | Low-count, easy strip | FRP or steel | LSZH/PE |
Equipment Ensuring Quality and Throughput
Automation with sensor feedback at Shanghai Weiye OFC Equipment cut manual handling and increase throughput for patch cord prep.
Our production line integrates automated machines that cut/strip drop cords to raise throughput and cut labor variability.
The CLX-BPO2 auto-stripping machine runs under PLC and photoelectric control. One cycle is ~1.5 s, giving real-world speeds near 20 terminal operations per minute.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH and PVC jackets and trims FRP or steel strength members to precise stub lengths. Cylinder-driven actuators provide quick, repeatable motion and low downtime.
Closed-Loop Control for Repeatability
PLC logic + photoelectric sensors deliver precise positioning and closed-loop control. Inline checks feed control charts so operators can adjust drifts before defects grow.
| Feature | Spec | Benefit |
|---|---|---|
| CLX-BPO2 | 1.5s cycle, auto-strip | ~20 terminals/minute throughput |
| Actuation | Pneumatic cylinders | Fast/reliable motion |
| Materials | LSZH/PVC; FRP/steel | Accurate stubs, clean terminations |
| Process control | PLC + photoelectric + inline checks | Stable quality, reduced rework |
- Auto scrap ejection and ergonomic feeders maintain clean workcells.
- PCPs document calibration and key parameters.
- Integrated assets and trained operators help meet FTTH volume goals without compromising accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while maintaining consistent prep.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to increase throughput and standardize prep quality. The unit cycles in ~1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC/photoelectric control deliver exact detection and repeatable motion. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Throughput & Cycle Time
Typical operation speed is 1.5s per cycle. This enables steady throughput under continuous line conditions.
Supported Strip and Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable jacket strip length from 17.5–35.0 mm. Reserved strength member stubs are set between 7.0 and 11.0 mm to fit common termination hardware.
Handling FRP and steel wire strength members
The machine cleanly cuts FRP and steel wire strength elements while protecting neighboring fibers. Customized cutters are offered for non-standard cross-sections to maintain precision.
- Auto-eject scrap and sensor start cut idle time.
- Small footprint (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg weight simplify cell integration.
- Cylinder-driven motion and closed-loop control improve line reliability and reduce maintenance downtime.
| Specification | Value | Benefit |
|---|---|---|
| Cycle time | ~1.5 s (~20/min) | High throughput for production runs |
| Strip lengths (A) | 17.5–35.0 mm | Fits common connector processes |
| Reserved stub (B) | 7.0 to 11.0 mm | Supports termination strength |
| Power & size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams get drop parts install-ready. The CLX-BPO2 supports our lines in meeting volume targets without sacrificing quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures each build to meet your network requirements and simplify field rollout. We combine focused options with predictable schedules so your teams get install-ready reels.
Choose 1–4 core designs with single-mode or multimode fiber. Options include OS1, OS2, and OM2–OM4 along with G.652D and G.657 variants to match your optics and connector plans.
We match sheath colors to Pantone codes for fast field ID and consistent asset tagging.
Branding and Print Options
Select LSZH, PVC, or PE jackets based on route and safety rules. Custom print legends and logos support inventory and warranty tracking.
Put-Ups, Packaging, and Structures
Standard put-ups are 1/2/4 km with custom reels and packaging to suit storage and handling. Choose bow-type flat or self-supporting designs and FRP or steel members to fit span and isolation requirements.
| Option | Common choice | Benefit |
|---|---|---|
| Length | 1 / 2 / 4 km | Simpler staging and reels |
| Jacket | LSZH, PE, PVC | Indoor/Outdoor fit |
| Structure | Flat bow / Self-supporting | Flexible routing/span |
As a manufacturer, Shanghai Weiye aligns runs to your schedule and provides docs that detail final specs for straightforward QA on site.
QA, Testing & Documentation
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item ships with recorded acceptance data.
Lab Testing: Heat, Salt Spray & Vibration
Our lab conducts high-temperature exposure, salt spray corrosion, and mechanical vibration to qualify materials/assemblies. These tests recreate field stresses for indoor and outdoor use.
Per-Reel 100% Reports
Every fiber optic cable includes a 100% test report that records loss, return loss, and key geometry where applicable. Final QC gates stop nonconforming items before they leave the factory.
Traceability & Compliance
Batch records tie test data to reels and serials so audits and warranty claims are simple to verify. Documentation uses standard customer templates to accelerate approvals and receiving inspection.
- Line checks and final inspection prevent field failures and lower warranty events.
- Quality packages include specifications confirmation and formatted data for rapid review.
- Ongoing trend analysis drive preventive maintenance and raise long-term reliability.
| Test | Why | Result |
|---|---|---|
| Heat exposure | Thermal stability | Validated heat endurance |
| Salt spray | Corrosion resistance | Outdoor suitability |
| Vibration | Resistance to vibration | Reduced field failures |
Pricing and cost drivers for FTTH drop cable
Budget planning for a drop starts with fiber and jacket choices and is shaped by volume and customization.
Typical prices range broadly—from about $30 to $1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket material, length, and design structure.
Materials, Grade, Jacket & Structure
The primary cost drivers are fiber grade, sheath material, and the structural type chosen for deployment.
Self-supporting structures and steel members increase material/labor. Custom colors, logos, and print legends add setup and influence price for short runs.
Order length, volume, and customization impact on price
Longer reels and higher volume orders reduce unit cost. Small quantities often carry setup fees and higher per-unit charges.
- Line changeovers and custom tooling extend lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment match quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets over phases.
| Factor | Price impact | Recommendation |
|---|---|---|
| Optical grade | Large | Balance spec vs. budget |
| Sheath material | Medium | Evaluate LSZH vs PE |
| Length/Volume | High impact | Consolidate where possible |
Lead times, MOQ, and delivery for the United States
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align staffing and sites. Predictable schedules reduce downtime and help control cost when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for orders under 500 km. We plan capacity to match your rollout milestones and to keep deliveries on time.
The service team issues production updates and tracking so installation teams know when reels arrive. For tight schedules, we hold contingency capacity to accelerate critical-path orders.
Minimum order quantity and why it matters
The MOQ is one kilometer. This reflects line setup such as wire and jacket die adjustments that use startup material and generate scrap.
We review your length and staging plans to select reels to reduce waste/handling. Staggered batches can balance inventory holding with more frequent small-site deliveries.
Installation readiness and application scenarios
Site conditions dictate whether a self-supporting aerial, ducted pull, or direct-buried run is the best fit for a project.
Aerial vs Duct vs Direct-Buried
For aerial runs, Shanghai Weiye OFC Equipment advises self-supporting designs with appropriate members to control sag and tension for long-term reliability.
Duct installations perform best with low-friction sheaths and crush-resistant constructs so pulling does not damage fibers. PE jackets are common for underground and buried paths where moisture resistance matters.
Direct-buried designs require proper depth control per local codes and moisture barriers to protect the optic core over time.
Indoor Distribution and ONT
Indoor riser and plenum routes favor LSZH jackets to meet smoke/flame codes. Flat drop cable forms strip cleanly and present controlled stubs for fast ONT terminations.
We guide the choice of steel or FRP (dielectric) strength members based on bonding requirements, lightning exposure, and hardware compatibility. Standardized line prep shortens install time and reduces scrap.
| Scenario | Key design | Installer note |
|---|---|---|
| Overhead | Self-supporting (steel/FRP) | Verify messenger hardware/tension |
| Duct | Low-friction, crush-resistant | Use pull tape + lubricant |
| Direct burial | PE jacket, moisture barrier | Follow depth/warning tape codes |
| Indoor | LSZH with tight-bend support | Maintain bend radius at wall penetrations |
Our approach ensures a consistent install experience across indoor/outdoor transitions. That leads to fewer callbacks, faster activations, and stable field performance for your system.
Comprehensive Support & After-Sales
Our team coordinates testing, scheduling, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews share a unified plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full test reports and traceability to help QA acceptance.
- Round-the-clock availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Coordination of line schedules for urgent changes or acceleration requests.
- Config control so shipped items match agreed requirements every time.
| Area | What we do | Outcome |
|---|---|---|
| Tech/Eng | Spec review & pre-production builds | Fewer field issues |
| QA/Testing | Lab + 100% reports | Full traceability |
| Service | Rapid replacement & root-cause | Lower downtime |
Conclusion
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We provide custom FTTH drops that pair material choices with validated manufacturing and lab testing. Every reel ships with a 100% test report and documented lab trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2-enabled prep machines, cuts variability and shortens turnaround. Our equipment set standardize strip and stub lengths so installers get consistent results at turn-up.
From fiber selection to jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated customer support covers scheduling/logistics/after-sales so your deployment remains on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specs, timeline, and volume. We stand behind every shipment with laboratory validation and responsive service.
